AP One AX Lite
Feature Highlights
Integrated Wi-Fi 6 Technology
Delivers 45% faster speeds than Wi-Fi 5, supports 4× more device capacity, and improves power efficiency for connected devices.
Centralized Cloud Management
InControl integration allows full network control from any web browser—manage SSIDs, radio settings, and event logs with no extra hardware.
Custom Captive Portals
Create branded user experiences through turnkey or fully customizable captive portals in InControl.
Enterprise-Grade Roaming
Supports 802.11k/v/r for seamless and fast roaming across multiple access points.
SD-WAN Integration
Easily integrates with Peplink SD-WAN solutions to enhance network flexibility and simplify management.
Featured Solutions
Smart Cities
IoT
Resources
Specification Details
| Ethernet Port | 1x Gigabit Ethernet |
| Wi-Fi Standard | Wi-Fi 6 |
| Data Rates | 2×2 MU-MIMO 2.4 GHz: up to 574Mbps 5 GHz: up to 1200Mbps |
| Recommended Concurrent Users Per Radio | |
| Multiple SSIDs | |
| Transmit Power | 2.4GHz: 24dBm 5GHz: 25dBm |
| Antenna | Built-in Omni antenna |
| Antenna Gain | 2 x 3dBi for 2.4GHz 2 x 3dBi for 5GHz |
| Enclosure | Plenum-rated, Indoor Plastic |
| Dimensions | 5.9 x 5.9 x 1.3 inches 160 x 160 x 33 mm |
| Weight (Pound) | 0.84 pounds |
| Weight (Kilogram) | 382 grams |
| Power Input | DC Jack: 12V DC (Plug 5.5 x 2.1 mm, center positive) 802.3at PoE+ |
| Power Consumption | 14.5W (max.) |
| Operating Temperature | 32° – 104°F 0° – 40°C |
| Humidity | 15% – 95% (non-condensing) |
| Certifications | FCC, CE, RoHS |
| Warranty | 1-Year Limited Warranty |
| Package Content | AP One AX Lite Ceiling Mount Base (9/16” T-Rail) Ceiling Mount Base (15/16” T-Rail) Mounting Screw Set |
Deepdive
| Category | Details |
|---|---|
| Network | Bridge Mode Router (NAT) Mode Mesh Wireless Distribution System (WDS) Support for PPPoE, Static IP, DHCP Management VLAN Spanning Tree Protocol |
| Radio | Multiple SSID Auto Channel Selection Transmit Power Adjustment Neighbor AP Detection |
| AP Security | Open (No Encryption) Enhanced Open (OWE) WPA3 – Personal (AES:CCMP) WPA3 – Enterprise (AES:CCMP) WPA2/WPA3 – Personal (AES:CCMP) WPA2 – Personal (AES:CCMP) WPA2 – Enterprise (AES:CCMP) WPA/WPA2 – Personal (TKIP/AES: CCMP) WPA/WPA2 – Enterprise (TKIP/AES: CCMP) |
| Device Management | Web Administrative Interface InControl Cloud Management Peplink AP Controller SNMP v1, v2c and v3 |
| Client Management | Per SSID VLAN with QoS (802.1p/802.1q) Bandwidth Control MAC Address Filtering Layer 2 Client Isolation Limit on Max. Number of Clients Per Client VLAN with RADIUS VLAN with VLAN Pool Bandwidth Control Multicast Filter IGMP Snooping/Multicast Enhancement |
| Captive Portal | by InControl |
Ordering Information
| Product Code | Description |
|---|---|
| APO-AX-LITE | AP One AX Lite - 2x2 MU-MIMO Wi-Fi 6 AP for business, manageable by InControl. Simultaneous Dual-Band 802.11ax/ac/b/g/n |
Featured Add-on
| Product Code | Description |
|---|---|
| ACW-107 | 802.3af/at PoE Injector. Compatible with MAX Hotspot and AP One AX Series |
| ACW-602 | 1x12V3A Power Supply. Compatible with MAX HD2 and AP One AX Series |
| SVL-APO-AX-LITE-1Y | 1-Year Essential Care for AP One AX Lite |
| SVL-APO-AX-LITE-2Y | 2-Year Essential Care for AP One AX Lite |
| ICS-012 | 1-Year InControl 2 Subscription |
| ICS-024 | 2-Year InControl 2 Subscription |
| ECP-A-1Y | EssentialCare+ A (1-Year) |
| ECP-A-2Y | EssentialCare+ A (2-Year) |
| ECP-A-4Y | EssentialCare+ A (4-Year) |
