AP One Mini
Feature Highlights
Fast Wi-Fi Performance
Delivers high-speed 802.11ac Wave 2 Wi-Fi with multi-user MIMO for faster and more efficient wireless connections.
MU-MIMO Technology
Supports simultaneous data transmission to multiple devices using MU-MIMO and beamforming, improving network efficiency and performance.
Compact & Durable Design
Small form factor (3.9″ x 3.9″ x 0.8″), plenum-rated, and flame-resistant — perfect for discreet and safe installations.
Enhanced Network Features
Includes built-in PoE, user access control, and social Wi-Fi hotspot capabilities to optimize network flexibility.
Centralized Management
Easily manage locally via AP Controller on Balance routers or remotely through InControl 2 cloud platform.
Complete Network Solution
Seamlessly integrates with Balance routers for high-speed, reliable, and unified network performance.
Featured Solutions
Smart Cities
IoT
Resources
Specification Details
| Ethernet Port | 1x Gigabit Ethernet |
| Wi-Fi Standard | Wi-Fi 5 |
| Data Rates | 2×2 MU-MIMO 2.4GHz: up to 300Mbps 5GHz: up to 866Mbps |
| Recommended Concurrent Users Per Radio | |
| Multiple SSIDs | |
| Transmit Power | 2.4GHz: 22dBm 5GHz: 23dBm |
| Antenna | Built-In Omni Antenna |
| Antenna Gain | 2.2dBi for 2.4GHz 3dBi for 5GHz |
| Enclosure | Plenum-rated, Indoor Plastic |
| Dimensions | 3.9 x 3.9 x 0.8 inches 98 x 98 x 19.7 mm |
| Weight (Pound) | 0.33 pounds |
| Weight (Kilogram) | 150 grams |
| Power Input | AC Adapter: AC Input 100V – 240V / DC Output 12V, 802.3af PoE (Injector Not Included) |
| Power Consumption | 9.5W (max.) |
| Operating Temperature | 23° – 113°F -5° – 45°C |
| Humidity | 15% – 95% (non-condensing) |
| Certifications | FCC, CE, RoHS |
| Warranty | 1-Year Limited Warranty |
| Package Content | AP One Mini, 12V2A Power Supply (ACW-601), 1x Mounting Bracket |
Deepdive
| Category | Details |
|---|---|
| Network | Bridge Mode Router (NAT) Mode Wireless Distribution System (WDS on 2.4GHz Only) Support for PPPoE, Static IP, DHCP Management VLAN (802.1p) Spanning Tree Protocol (802.1d) |
| Radio | Multiple SSID Auto Channel Selection Transmit Power Adjustment Neighbour AP Detection |
| AP Security | Open (No Encryption) OWE WPA3 – Personal WPA3 – Enterprise WPA2/WPA3 – Personal WPA2 – Personal WPA2 – Enterprise WPA/WPA2 – Personal WPA/WPA2 – Enterprise |
| Device Management | Web Administrative Interface InControl Cloud Management Peplink AP Controller SNMP v1, v2c and v3 |
| Client Management per SSID | VLAN with QoS (802.1p/802.1q) Bandwidth Control MAC Address Filtering Layer 2 Client Isolation Limit on Max. Number of Client |
| Client Management per Client | VLAN with RADIUS VLAN with VLAN Pool Bandwidth Control Multicast Filter IGMP Snooping/Multicast Enhancement |
| Complete SpeedFusion VPN Solution | Site-to-Site VPN 256-bit AES Encryption Pre-shared Key Authentication Dynamic Routing |
| Captive Portal | By InControl |
Ordering Information
| Product Code | Description |
|---|---|
| APO-AC-MINI | AP One Mini - Simultaneous 802.11ac wave 2/ac/a/n 866Mbps and 802.11b/g/n 300Mbps. Built-in omni antenna included. |
Featured Add-on
| Product Code | Description |
|---|---|
| ACW-384 | AP One Mini Protect Cover |
| SVL-791 | 1-Year EssentialCare for AP One Mini |
| SVL-691 | 2-Year EssentialCare for AP One Mini |
| ICS-012 | 1-Year InControl 2 Subscription |
| ICS-024 | 2-Year InControl 2 Subscription |
| ECP-A-1Y | EssentialCare+ A (1-Year) |
| ECP-A-2Y | EssentialCare+ A (2-Year) |
| ECP-A-4Y | EssentialCare+ A (4-Year) |
