SIM Injector
Feature Highlights
Expand SIM Capacity
Add 8 additional SIM cards to your deployment for access to multiple carriers and improved connection redundancy.
Power over Ethernet (PoE)
Provides PoE output to simplify installation—no additional PoE switch required.
Flexible Deployment
Extend up to 100 meters between the router and SIM cards, allowing optimal router placement without frequent SIM changes.
Scalable Architecture
Supports multiple SIM Injectors, enabling a single router to access all connected SIMs for maximum flexibility and uptime.
Featured Solutions
Smart Cities
Event
Transportation
Resources
Specification Details
| SIM Slots | 8x Active SIM Slots, Mini-SIM (2FF) |
| LAN Interface | 4x GE |
| Power Input | DC Jack / Terminal Block: 12-56V |
| Power Output | Up to 4x 802.3at PoE+ Outputs (up to 30W per port) |
| Dimensions | 1.6 x 5.8 x 5 inches 40 x 147 x 128 mm |
| Power Consumption | 10W (nominal), 130W (max. with 4x802.3at PoE+ Outputs) |
| Weight | 430 grams 0.94 pounds |
| Operating Temperature | -40° – 149°F -40° – 65°C |
| Humidity | 15% – 95% (non-condensing) |
| Package Content | 1x SIM Injector Power cable (ACW-614) Power supply (ACW-622) |
Ordering Information
| Product Code | Description |
|---|---|
| SIM-BK8-4E-56V | SIM Injector, 8x SIM cards capacity, 4x 10/100/1000 LAN ports, 56V DC |
| SIM-BK8-4E-56V-DOM | SIM Injector (bundle offer), 8x SIM cards capacity, 4x 10/100/1000 LAN ports, 56V DC |
Featured Add-on
| Product Code | Description |
|---|---|
| SVL-496 | EssentialCare (1-Year) for SIM Injector |
| SVL-591 | EssentialCare (2-Year) for SIM Injector |
| ECP-SIM-BK8-1Y | EssentialCare+ (1-Year) for SIM Injector |
| ECP-SIM-BK8-2Y | EssentialCare+ (2-Year) for SIM Injector |
| ECP-SIM-BK8-4Y | EssentialCare+ (4-Year) for SIM Injector |
More Information in Datasheet
Technical Drawing
Cellular Antenna Performance
Wi-Fi Antenna Performance
Cellular & Wi-Fi Antenna Performance
Radiation Pattern
Installation Recommendation
Packing List Information
FAQ
